Home > Products > Porcelain Insulator > Station Post Insulator > Porcelain Station Post Insulator TR-316

View the big picture

Porcelain Station Post Insulator TR-316

Payment Type:	L/C,T/T
Incoterm:	FOB,CFR,CIF
Min. Order:	1000 Piece/Pieces
Delivery Time:	30 Days

Contact Now

Basic Info

Model No.: TR-316

Color: Brown , Light Grey

Place Of Origin: Fuzhou,China

HS Code: 85462090

Application: High-voltage

Material: Porcelain

Structure: Post Insulator

Usage: High Voltage Power Transmission

Connection Method: Trough Type

Certification: SGS, ISO9001

Additional Info

Packaging: Carton, Wooden case, Sack

Transportation: Ocean,Land

Port: FUZHOU

Product Description

Porcelain Station Post Insulator TR-316

1. Post insulator size:TR-202,TR-205,TR-208,TR-214,TR-216,TR-231,TR-267,TR-278,TR-286,TR-288,TR-308,TR-316

2. This post insulator substation is solid-core station post insulators.

3.ANSI post insulators

MAIN DIMENSIONS AND STANDARD PARTICULARS
ANSI Class		TR-316
Creepage Distance/mm		5029
Cantilever Strength/kn		5.56
Tensile Strength/kn		111
Torsional Strength/k.m		10170
Compression Strength/kn		333
Low Frequency Flashover Voltage	Dry /kv	660
	Wet/kv	570
Critical Impulse Flashover Voltage	Pos/kv	1210
	Neg/kv	1450
Low Frequency Withstand Voltage	Dry/kv	545
	Wet/kv	455
Impulse Withstand Voltage/kv		1050
Net Weight/kg		150
Applicable Standard		ANSI C29.9

Our Services

1. Small Orders Accepted
2. Fast producing time, Prompt Delivery
3. International Approvals
4. Reply promptly in 24 hours
5. Best Price

FAQ:

1. Q: How about payment terms?
A: 30% TT deposit + 70% TT before shipment,50% TT deposit + 50% LC balance, Flexible payment can be negotiated.
2. Q: Do you have some videos where we can see the line producing?
A: Yes, we can provide some videos for reference.
3. Q: Are you a Manufacture Factory?
A: Yes. We are the direct manufacture factory, and our factory has specialized in Porcelain Insulator,Composite Insulator,Glass Insulator,arrester, Cold And Heat Shrinkable Tube,Cut Out Fuse and Power Fitting ,etc.

4. Q: How long is producing time ?

A: Normally it will take about 30 days for production.

5. Q: What is the standard of package ?
A: For small capacity, we use carton, but for big capacity, we will use strong wooden case for protection or double inner packs in a master carton.
6. Q: How do you make sure your good quality ?

A: We use the best raw material , and every single product will go through a series of strict test.
